Cotton Conveyor Belt conveyor belt manufacturer from China Baoding Huayun Conveyor Machinery Co., Ltd

Payment Terms:	T/T,L/C,WU,Paypal
Place of Origin:	Hebei, China (Mainland)

Product Detail

Production Capacity: 2000 pieces / day

Delivery Date: 7-30days

Packing: Wooden case

Cotton Conveyor Belt

1. Applications

Cotton conveyor belt is suitable for transportation of short-distance, medium quantity.

2. Physical properties of rubber cover (before aging)

Grade	Tensile Strength/Mpa ≥	Breaking Elongation/% ≥	Abrasion Loss/mm3 ≤
H	24	450	120
D	18	400	100
L	15	350	200
Note: Grade H-used for transporting sharp, abrasive materials which can damage belts badly. Grade D-used for transporting highly abrasive materials. Grade L-used for transporting medium-abrasion materials.

After-aging properties of rubber cover(70℃, 7days):

Tensile strength and breaking elongation are both not lower than 75% of before-aging values.

3. Ply adhesion

Item	Ply to ply	Rubber cover to ply
Item	Ply to ply	Rubber cover thickness ≤1.5mm	Rubber cover thickness >1.5mm
All samples average value/ (N/mm) ≥	3.2	2.1	2.7
All samples min peak value/ (N/mm) ≥	2.7	1.6	2.2
Note: All samples max peak value is not more than 20N/mm.
